Titanium Woven Wire Mesh

Titanium Woven Wire Mesh

Titanium woven wire mesh is a kind of products with outstanding corrosion resistance, low density and nontoxic performance. In the corrosion environment, the surface of high purity titanium mesh will form an oxidation film layer to protect wire mesh from being corroded. The layer is compact and inert, which has strong resistance to the corrosion.

Best Quality
High efficiency
Customize

Inquiryt

Description
About Manufacturer

Description

Titanium woven wire mesh is a kind of products with outstanding corrosion resistance, low density and nontoxic performance. In the corrosion environment, the surface of high purity titanium mesh will form an oxidation film layer to protect wire mesh from being corroded. The layer is compact and inert, which has strong resistance to the corrosion. It has excellent corrosion resistant performance in below environment: Seawater, wet chlorine, chlorite and hypochlorite solution, nitric acid, chromic acid, metal chlorides and organic salts.

Because of the outstanding corrosion resistance, the titanium woven wire mesh has become the replacement material of nickel-free stainless steel wire mesh, aluminum wire mesh.

The titanium wire mesh has expanded wire mesh and perforated wire mesh types, which can be used for different applications.

Titanium Woven Wire Mesh Knitted Wire Mesh

Specifications

Material grade: TA1, TA2 GR1, GR2, R50250.
Weaving type: plain weave, twill weave and dutch weave.
Wire diameter: 0.002" - 0.035".
Mesh size: 4 mesh - 150 mesh.
Color: black or bright.

Item	Mesh (Wires/ in.)	Wire diameter (in.)	Width of opening (in.)	Open area (%)
AHS-I-01	4 × 4	0.0320	0.2180	76.00
AHS-I-02	4 × 4	0.0350	0.2150	74.00
AHS-I-03	6 × 6	0.0320	0.1350	65.60
AHS-I-04	7 × 7	0.0250	0.1180	68.20
AHS-I-05	8 × 8	0.0320	0.0930	55.40
AHS-I-06	9 × 9	0.0320	0.0790	50.60
AHS-I-07	10 × 10	0.0350	0.0650	42.30
AHS-I-08	10 × 10	0.0300	0.0700	49.00
AHS-I-09	10 × 10	0.0250	0.0750	56.30
AHS-I-10	12 × 12	0.0110	0.0723	75.30
AHS-I-11	14 × 14	0.0160	0.0550	60.20
AHS-I-12	16 × 16	0.0060	0.0565	81.70
AHS-I-13	18 × 18	0.0100	0.0460	67.40
AHS-I-14	18 × 18	0.0110	0.0445	64.40
AHS-I-15	18 × 18	0.0160	0.0400	50.8
AHS-I-16	20 × 20	0.0030	0.0470	88.40
AHS-I-17	20 × 20	0.0200	0.0300	36.00
AHS-I-18	20 × 20 TW	0.0160	0.0340	46.20
AHS-I-19	24 × 24	0.0100	0.0320	57.90
AHS-I-20	24 × 24	0.0118	0.0299	51.40
AHS-I-21	26 × 26	0.0100	0.0290	54.90
AHS-I-22	30 × 30	0.0100	0.0233	49.00
AHS-I--23	32 × 32	0.0100	0.0210	46.50
AHS-I-24	35 × 35	0.0080	0.0206	51.80
AHS-I-25	40 × 40	0.0050	0.0200	64.00
AHS-I-26	40 × 40	0.0100	0.0150	36.00
AHS-I-27	50 × 50	0.0090	0.0110	30.30
AHS-I-28	50 × 50 TW	0.0040	0.0160	64.00
AHS-I-29	60 × 60 TW	0.0090	0.0077	21.30
AHS-I30	90 × 90	0.0040	0.0071	41.00
AHS-I-31	100 × 100	0.0020	0.0080	64.00
AHS-I-32	120 × 120 TW	0.0040	0.0043	27.00
AHS-I-33	150 × 150 TW	0.0027	0.0040	35.50

Features

Low density and high tensile strength.
Excellent Corrosion resistance.
High temperature resistance.
Outstanding filtration performance.
Good thermal property.
Acid and alkali resistance.
Nontoxic.

Package

Waterproof brown paper.
Plastic film.
Wooden box.
Pallet.
